R-460 Railgear


G & B Specialties Model R-460 is applicable to vehicles up to 19,500 lbs GVWR. This 100% duty cycle railgear was designed to meet the task at hand. Proven “Cushion-Ride” suspension provides ride quality , reduced vibration through the vehicle frame, less component stress, and constant rail wheel to rail contact. No railgear adjustments are required for varying loads. With Rafna-Cushion-Ride Railgear, there are no limits imposed. If the vehicle can support the load, so can the railgear. Rafna R-460 Railgear has two hydraulic cylinders on both the front and rear units, providing power to spare under full vehicle capacity. On rail, the vehicle’s front wheels are raised a minimum of 2” above the rail head and the vehicle axle is hydraulically locked in place. Stock tires to be changed from 225/70R19.5 to 245/70R19.5.

Standard Features:

  • Cushion-Ride Rubber Suspension
  • Automatic Locking System
  • PTO Pump Application
  • Built-In Derail Skids
  • Rail Sweeps Front and Rear
  • Grease Fittings at All Wear Points


  • Full Track Circuit Insulation (All Four Wheels)
  • Hydraulic Operating Valves on the Front and Rear Units
  • Protective Bellows Over All Inner Guide Tubes
  • Mechanical Steering Wheel Lock
  • Hydraulic Rear Railgear Lock-Up
  • Corrosion Resistant; Long Life Fasteners

Optional Features:

  • Electric/Hydraulic Package with Exterior Composite
  • Brake Shoes. Available in 2 or 4 Wheels
  • 12VDC Pump and Reservoir
  • Mechanical Rear Railgear Lock Up
  • Heavy Duty Springs for Rear Unit
  • Rod Actuated Vehicle Axle Lock

Vehicle Classification:

Vehicle Applications:

  • GVWR 19,500 lbs MAX
  • GAWR (Front) – 7,600 lbs
  • GAWR (Rear) – 11,900 lbs
  • 2008 & Up Ford F-450/550 Chassis
  • 4X2/4X4
  • Gas/Diesel
  • RAM 4500/5500

Wheels: R-460

  • Material Forged Steel
  • Tread 10” Diameter
  • Flange 12-1/4” Diameter
  • Bearings HD Tapered Roller
  • Grease Cap w/ Vent

Installed Weight R-460

  • Total 980 lbs
  • Front 440 lbs
  • Rear 540 lbs
